Ringlock Scaffolding
Double Ledger
Technical Specifications
- Material Grade High-Yield Structural Steel (Q235 / Q345)
- Surface Treatment Hot-Dip Galvanized
- Available Lengths (Metric) 1.57 Mtr. | 2.07 Mtr. | 2.57 Mtr. | 3.07 Mtr.
- Available Lengths (Imperial) 5.2 Ft. | 6.8 Ft. | 8.4 Ft. | 10.1 Ft.
- Weight Variations (Metric) 11.66 Kg | 17.87 Kg | 19.10 Kg | 21.50 Kg
- Weight Variations (Imperial) 25.7 Lbs | 39.4 Lbs | 42.4 Lbs | 47.4 Lbs
- Tube Diameter Standard 48.3 mm
- Connection Mechanism Ledger End with Captive Wedge Pin
- Origin India
Product Description
In complex industrial builds, standard horizontal supports are often insufficient for wide spans or heavy material staging. The double ledger solves this critical engineering challenge. By utilizing a reinforced twin-tube design, it exponentially increases the load-bearing capacity of the scaffolding bay, allowing for safe storage of masonry blocks, heavy tools, and larger work crews without the risk of structural bowing or fatigue.
Precision Configurations for Exact Site Demands
B2B procurement requires exact metrics to eliminate worksite friction. As detailed in the standard specifications from image_f85c6a.png, our double ledgers are manufactured to exact tolerances across four distinct sizes. For highly localized load reinforcement, our 1.57 Mtr. (11.66 Kg) and 2.07 Mtr. (17.87 Kg) options provide rigid, compact strength. For wider platform spans requiring massive support, we offer the 2.57 Mtr. (19.10 Kg) and maximum-reach 3.07 Mtr. (21.50 Kg) ledgers. These precise weight-to-length ratios allow site engineers to perfectly calculate structural loads while maintaining efficient on-site material handling.
Frictionless Installation and Superior Durability
Our double ledgers are engineered to lock flawlessly into standard Ringlock and modular rosettes. The precision-machined ledger ends with captive wedge pins allow scaffolding crews to secure the horizontal beams with a single hammer blow, drastically reducing erection times. Furthermore, to combat the corrosive elements of coastal or chemical-heavy worksites, every double ledger undergoes a strict hot-dip galvanization process. This thick zinc shield guarantees long-term rust prevention, ensuring your scaffolding fleet retains its structural integrity and delivers maximum ROI project after project.
| Feature | Specification |
| Material Grade | High-Yield Structural Steel (Q235 / Q345) |
| Surface Treatment | Hot-Dip Galvanized |
| Available Lengths (Metric) | 1.57 Mtr. | 2.07 Mtr. | 2.57 Mtr. | 3.07 Mtr. |
| Available Lengths (Imperial) | 5.2 Ft. | 6.8 Ft. | 8.4 Ft. | 10.1 Ft. |
| Weight Variations (Metric) | 11.66 Kg | 17.87 Kg | 19.10 Kg | 21.50 Kg |
| Weight Variations (Imperial) | 25.7 Lbs | 39.4 Lbs | 42.4 Lbs | 47.4 Lbs |
| Tube Diameter | Standard 48.3 mm |
| Connection Mechanism | Ledger End with Captive Wedge Pin |
| Origin | India |
Application & Additional Information
Engineered for extreme load-bearing capacities and wide-span structural integrity, our double ledger is the ultimate horizontal reinforcement for modular scaffolding systems. Manufactured from high-yield structural steel with a premium hot-dip galvanized finish, these ledgers are available in four precise configurations ranging from 1.57 Mtr. (5.2 Feet) to 3.07 Mtr. (10.1 Feet). Designed to prevent deflection under heavy dynamic loads, our double ledgers ensure uncompromising safety and rapid installation on demanding industrial construction sites
